Gweike M Series: The Ultimate 6-in-1 Laser Powerhouse!

Traditional fiber lasers have been costly and bulky, limiting their reach to home and small business now. The Gweike M Series 6-in-1 redefines accessibility, blending a 1200W fiber laser for precision metal cutting and welding with 130W CO2 lasers for intricate engraving and non-metal cutting. By eliminating the need for multiple machines, slashing costs with 5X faster welding, and delivering razor-sharp 0.02mm precision, making high-performance laser processing more affordable and accessible than ever.

6-in-1 Functions:

1. CNC fibre metal cutting (1200W Fibre laser for all metals)

2. CO₂ Cutting for non metals (wood, acrylic, etc.)

3. CO₂ Engraving

4. Fiber Welding

5. Fiber Laser Cleaning (rust, paint removal)

6. Hand held fiber cutting/welding

1,380mm × 920mm Work Area

Price includes GST, please contact us for shipping quote and delivery arrangements

M3 ULTRA Specifications

Machine Size & Weight

CNC gantry unit: 2 185 × 1 780 × 1 100 mm (L × W × H)

Hand-held fiber module: 620 × 355 × 610 mm

Total weight: approx. 610 kg

Cable lengths: 10 m (CNC unit), 8 m (hand-held)

Laser Power & Working Area

Fiber laser: 1200 W

CO₂ laser: 130 W

Working area: 1380 × 920 mm (≈ 54″ × 36″)

Performance Specs

Fiber welding thickness: up to 0.2–5 mm

Cutting thickness: fiber ≤10 mm; CO₂ ≤20 mm

CNC engraving: up to 800 mm/s

CNC cutting: up to 500–600 mm/s

Position accuracy: ±0.03 mm; locating ±0.01 mm

Acceleration: up to 0.8 G (CNC)

Min engraving size: 1x 1 mm

Components & Software

Fiber source: MAXPhotonics or Raycus

CO₂ tube: RECI

Laser head/control: Au3tech, with Windows/Linux control software

Supported file formats: DXF, DWG, AI, PDF, DST, PLT, BMP, JPG, PNG

Cooling & Power

Cooling system: air + water chiller

Power input: dual 230 V, 50 Hz, 20 A single-phase

Optional Accessories

Dry Air Compressor, bed, rotary attachment, air filter, HP3000/20DYHY compressor

Industrial-grade exhaust/air regulation options

Highlights

Combines high-power fiber and CO₂ lasers in a single desktop system

Broad versatility: cutting, engraving, welding, cleaning, both CNC and hand-held
